ETON 11-612/C8/50 RP Bass-mid Woofer
Our Orchestra Series with traditional paper cone, newly interpreted with ETON’s expertise. The special, radial ribbing and long-fiber, highly absorbing paper mixture creates a very high degree of impulse
fidelity and precision, even at extremely high levels; not to mention the resulting individualized appearance. The special paper mixture guarantees homogeneity by preventing mode formations at all possible frequency ranges.
The Orchestra mid range drivers and woofers are characterized by their natural, warm sound. This results in a balanced, well-contoured and soft mid range. In the low frequency range, our Orchestra is more than convincing with its voluminous and impulsive bass response.
With its multiply ventilated and flow-supporting cast basket, the ferrite drive ensures that any occurring compression effects are reduced to a minimum.
Orchestra, a sonic reinterpretation with traditional materials.
Specifications
Article number11-612/C8/50 RP
EAN8785256846870
Woofer SeriesETON Orchestra series
Woofer TypeBass-mid Woofer
Nominal Diameter11"
Power Handling (RMS)120 Watts
Impedance (Z)8 Ω
Sensitivity (SPL at 1m / 2.83V)91 dB
DC Resistance (Re)5.3 Ω
Voice Coil Inductance (Le)1.03 mH
Resonant Frequency (Fs)23 Hz
Mechanical Q (Qms)7.87
Electromagnetic Q (Qes)0.30
Total Q (Qts)0.29
Moving Mass Of Diaphragm (Mmd)54 g
Mechanical Compliance of Suspension (Cms)0.81 mm/N
Surface Area of Cone (Sd)366 cm2
BL Product (BL)11.4 Tm
Compliance Equivalent Volume (Vas)152 dm3
Maximum Linear Excursion (Xmax)5 mm
Driver's Mechanical Losses (Rms)1.13 kg/s
Voice Coil FormerKapton
Magnet MaterialFerrite
Overall Outside Diameter280 mm
Overall Depth110.5 mm
Baffle Cutout Diameter242 mm
Mounting Hole Diameter5.5/9.7 mm
