FaitalPRO 15HX500-8P 15" Coaxial Woofer 8 Ohm

FaitalPRO 15HX500-8P Coaxial Woofer The FaitalPRO 15HX500 is a powerful coaxial loudspeaker combining a 15-inch LF woofer with a high-efficiency HF compression driver. Designed for full-range professional audio applications, it offers wide bandwidth, high SPL handling, and compact system integration in a single unit. Highlights of the FaitalPRO 15HX500 Integrated 15" low-frequency woofer and 2.9" high-frequency compression driver 400 W AES (LF) and 90 W AES (HF) power handling for high-output performance Excellent sensitivity: 97 dB (LF) and 105 dB (HF) for efficient system response Neodymium magnets for both LF and HF keep the weight at just 6.1 kg Product details FaitalPRO 15HX500 FaitalPRO 15HX500 Coaxial Loudspeaker Driver – 8 Ohm Version The FaitalPRO 15HX500 is a professional coaxial transducer integrating a 15-inch woofer and a 1.4" exit compression driver in a single frame. The LF section features a 77 mm (3 in) copper voice coil on a glass fiber former, handling up to 400 W AES and delivering deep, controlled bass from 40 Hz to 3150 Hz. The HF driver employs a 74 mm (2.91 in) aluminum voice coil with a titanium dome diaphragm and neodymium motor, offering smooth and extended high-frequency response from 500 Hz to 20 kHz. With 105 dB sensitivity in the HF and 97 dB in the LF, this coaxial driver is highly efficient and ideal for compact, high-output enclosures in stage monitors, front fills, or portable full-range systems. The integrated design improves phase coherence and reduces enclosure volume requirements, while the 900 Hz recommended crossover point ensures clean, natural transition between LF and HF sections. Its aluminum basket and demodulation ring in the woofer further enhance thermal and mechanical performance.
