Tweeter Type: Dome
Cone / Dome Diameter: 1-1/8"
Power Handling (RMS): 120 Watts
Impedance (Z): 8 ohms
Sensitivity: 89.8 dB 1W/1m
Frequency Response: 1,400 to 40,000 Hz
Resonant Frequency (Fs): 498 Hz
DC Resistance (Re): 6.8 ohms
Voice Coil Inductance (Le): 0.02 mH
Mechanical Q (Qms): 2.43
Electromagnetic Q (Qes): 0.72
Total Q (Qts): 0.56
