SICA 2 H 0,8 SL Full Range 8Ω

SICA 2 H 0,8 SL Full Range 8Ω

SICA 2 H 0,8 SL Full Range 8Ω

SICA 2 H 0,8 SL Full Range 8Ω

SICA 2 H 0,8 SL Full Range 8Ω

SICA 2 H 0,8 SL Full Range 8Ω

SICA 2 H 0,8 SL Full Range 8Ω

SICA 2 H 0,8 SL Full Range 8Ω

Shipping within (if available from supplier)

3-6 weeks

Manufacturer

Sica

Further data

Out of stock - orderable

Details

General Specifications

Nominal Diameter	53×53 mm / 2 in
Nominal Impedance	8 Ω
Rated Power AES	20 W
Continuos Program Power	40 W
Sensitivity @ 1W/1m	84.1 dB
Voice Coil Diameter	20 mm (0.8")
Voice Coil Winding Depth	4 mm
Magnetic Gap Depth	3 mm
Flux Density	1.30 T
Magnet Weight	16 g
Net Weight	0.1 Kg

Constructive Characteristics

Magnet Type	Neodymium
Basket Material	Nylon fiberglass doped
Voice Coil Winding Material	Aluminium
Voice Coil Former Material	Kapton
Cone Material	Paper
Cone Treatment	Surface Damping Treatment
Surround Material	Treated Cloth
Dust Dome Material	Solid Paper

Mounting Information

Overall Diameter	52.5×52.5 mm
Baffle Cutout Diameter	48 mm
Mounting Holes	4 holes Ø3,2 on Ø61,5 mm
Total Depth	32.5 mm

Thiele/Small Parameters

Re	5.5 Ω
Qms	2.75
Qts	0.81
Cms	603 µm/N
Vas	0.1 l
X max	+/- 1.4 mm
N	0.11 %
Fs	216.0 Hz
Qes	1.00
Mms	0.9 g
Bxl	2.60 Tm
Sd	11.3 cm²
X var	+/- 2.7 mm
Le (1KHz)	0.20 mH

Info

Impedance, Z

8

Chassis diameter

2-2.5”

Article No.

SIC-Z000795C

Weight

100 g/db
