SICA 3,5 H 1 CS Full Range
SICA 3,5 H 1 CS Full Range
23.04 € excl. VAT

SICA 3,5 H 1 CS Full Range

SICA 3,5 H 1 CS Full Range
SICA 3,5 H 1 CS Full Range
SICA 3,5 H 1 CS Full Range
SICA 3,5 H 1 CS Full Range
SICA 3,5 H 1 CS Full Range
SICA 3,5 H 1 CS Full Range
SICA 3,5 H 1 CS Full Range
SICA 3,5 H 1 CS Full Range
Manufacturer
Sica
Further data
In stock
23.04 € excl. VAT
Details
General Specifications
Nominal Diameter

88 mm / 3.5 in
Nominal Impedance

8 Ω
Rated Power AES

45 W
Continuos Program Power

90 W
Sensitivity @ 1W/1m

86.1 dB
Voice Coil Diameter

25 mm (1")
Voice Coil Winding Depth

9 mm
Magnetic Gap Depth

4 mm
Flux Density

1.04 T
Magnet Weight

160 g
Net Weight

0.4 Kg
Constructive Characteristics
Magnet Type

Ferrite
Basket Material

Nylon fiberglass doped
Voice Coil Winding Material

Copper
Voice Coil Former Material

Kapton
Cone Material

Paper
Cone Treatment

Surface Waterproof Treatment
Surround Material

Rubber
Dust Dome Material

Treated Cloth
Mounting Information
Overall Diameter

88 mm
Baffle Cutout Diameter

81 mm
Mounting Holes

4 holes Ø4 on Ø98 mm
Total Depth

44.7 mm
Thiele/Small Parameters
Re

6.1 Ω
Qms

6.95
Qts

0.53
Cms

855 µm/N
Vas

1.8 l
X max

+/- 2.5 mm
N

0.19 %
Fs

85.0 Hz
Qes

0.57
Mms

4.1 g
Bxl

4.83 Tm
Sd

38.5 cm²
X var

+/- 4.2 mm
Le (1KHz)

0.40 mH
Info
Impedance, Z
8
Chassis diameter
3-3.5”
Article No.
SIC-Z000957C
Weight
400 g/db
