SICA 4 E 1 CS Full Range

SICA 4 E 1 CS Full Range

SICA 4 E 1 CS Full Range

SICA 4 E 1 CS Full Range

SICA 4 E 1 CS Full Range

SICA 4 E 1 CS Full Range

SICA 4 E 1 CS Full Range

SICA 4 E 1 CS Full Range

Shipping within (if available from supplier)

3-6 weeks

Manufacturer

Sica

Further data

Out of stock - orderable

Details

General Specifications

Nominal Diameter	102 mm / 4 in, 104 x 104 mm / 4 in
Nominal Impedance	8 Ω
Rated Power AES	70 W
Continuos Program Power	140 W
Sensitivity @ 1W/1m	90.2 dB
Voice Coil Diameter	25 mm (1")
Voice Coil Winding Depth	9 mm
Magnetic Gap Depth	6 mm
Flux Density	1.10 T
Magnet Weight	380 g
Net Weight	1.0 Kg

Constructive Characteristics

Magnet Type	Ferrite
Basket Material	Pressed Sheet Steel
Voice Coil Winding Material	Aluminium
Voice Coil Former Material	Aluminium
Cone Material	Paper
Cone Treatment	Surface Waterproof Treatment
Surround Material	Treated Cloth
Dust Dome Material	Polypropylene ogive

Mounting Information

Overall Diameter	104×104 mm
Baffle Cutout Diameter	90 mm
Mounting Holes	4 holes Ø5 on Ø106 mm
Total Depth	58.3 mm

Thiele/Small Parameters

Re	5.6 Ω
Qms	1.85
Qts	0.39
Cms	466 µm/N
Vas	1.3 l
X max	+/- 2.2 mm
N	0.42 %
Fs	118.0 Hz
Qes	0.49
Mms	3.9 g
Bxl	5.76 Tm
Sd	44.2 cm²
X var	+/- 3.5 mm
Le (1KHz)	0.14 mH

Info

Impedance, Z

8

Chassis diameter

4-4.5”

Article No.

SIC-Z001800C

Weight

1 kg/db
