SICA 5 D 1 CS Full Range
SICA 5 D 1 CS Full Range
27.92 € excl. VAT

SICA 5 D 1 CS Full Range

SICA 5 D 1 CS Full Range
SICA 5 D 1 CS Full Range
SICA 5 D 1 CS Full Range
SICA 5 D 1 CS Full Range
SICA 5 D 1 CS Full Range
SICA 5 D 1 CS Full Range
SICA 5 D 1 CS Full Range
SICA 5 D 1 CS Full Range
Manufacturer
Sica
Further data
In stock
27.92 € excl. VAT
Details
General Specifications
Nominal Diameter

129 mm / 5 in
Nominal Impedance

8 Ω
Rated Power AES

60 W
Continuos Program Power

120 W
Sensitivity @ 1W/1m

90.0 dB
Voice Coil Diameter

25 mm (1")
Voice Coil Winding Depth

9 mm
Magnetic Gap Depth

6 mm
Flux Density

0.95 T
Magnet Weight

280 g
Net Weight

0.9 Kg
Constructive Characteristics
Magnet Type

Ferrite
Basket Material

Pressed Sheet Steel
Voice Coil Winding Material

Copper
Voice Coil Former Material

Epotex
Cone Material

Paper
Cone Treatment

Surface Waterproof Treatment
Surround Material

Rubber
Dust Dome Material

Non Treated Cloth
Mounting Information
Overall Diameter

130 mm
Baffle Cutout Diameter

113 mm
Mounting Holes

4 holes 4,7×10 on Ø139 mm
Total Depth

58.1 mm
Thiele/Small Parameters
Re

6.0 Ω
Qms

4.95
Qts

0.52
Cms

634 µm/N
Vas

5.5 l
X max

+/- 3.0 mm
N

0.45 %
Fs

79.0Hz
Qes

0.58
Mms

6.4 g
Bxl

5.73 Tm
Sd

78.5 cm²
X var

+/- 4.5 mm
Le (1KHz)

0.33 mH
Info
Impedance, Z
8
Chassis diameter
5-5.5”
Article No.
SIC-Z002400C
Weight
900 g/db
