SICA 15 PFS 4 Woofer

264.96 € excl. VAT

SICA 15 PFS 4 Woofer

SICA 15 PFS 4 Woofer

SICA 15 PFS 4 Woofer

SICA 15 PFS 4 Woofer

SICA 15 PFS 4 Woofer

SICA 15 PFS 4 Woofer

SICA 15 PFS 4 Woofer

SICA 15 PFS 4 Woofer

Manufacturer

Sica

Further data

In stock

264.96 € excl. VAT

Details

General Specifications

Nominal Diameter	389 mm / 15 in
Nominal Impedance	8 Ω
Rated Power AES	1200 W
Continuos Program Power	2400 W
Sensitivity @ 1W/1m	95.8 dB
Voice Coil Diameter	100 mm (4")
Voice Coil Winding Depth	27 mm
Magnetic Gap Depth	12 mm
Flux Density	1.12 T
Magnet Weight	3300 g
Net Weight	12.3 Kg

Constructive Characteristics

Magnet Type	Ferrite
Basket Material	Aluminium Die-Cast
Voice Coil Winding Material	Copper
Voice Coil Former Material	Fiberglass
Cone Material	Paper
Cone Treatment	Total Waterproof Treatment
Surround Material	Treated Cloth
Dust Dome Material	Solid Paper

Mounting Information

Overall Diameter	388 mm
Baffle Cutout Diameter	355 mm
Mounting Holes	8 holes 6×9 on Ø371 mm
Total Depth	175.0 mm

Thiele/Small Parameters

Re	5.3 Ω
Qms	4.87
Qts	0.34
Cms	100 µm/N
Vas	103.9 l
X max	+/- 9.0 mm
N	1.61 %
Fs	39.0 Hz
Qes	0.37
Mms	166.5 g
Bxl	24.24 Tm
Sd	855.3 cm²
X var	+/- 9.0 mm
Le (1KHz)	1.80 mH

Info

Impedance, Z

8

Chassis diameter

15”

Article No.

SIC-Z008318

Weight

12.3 kg/db
