ÁLTALÁNOS ADATOK:
Nominal Diameter: 545 mm / 21 in
Nominal Impedence: 8 Ω
Rated Power AES (1): 1200 W
Continuous Program Power (2): 2400 W
Sensitivity @ 1W/1m (3): 98.8 dB
Voice Coil Diameter: 100 mm / 4 in
Voice Coil Winding Depth: 23 mm
Magnetic Gap Depth: 17 mm
Flux Density: 0.89 T
Magnet Weight: 536 g
Net Weight: 10.5 kg
:
FELÉPÍTÉS:
Magnet: Neodymium
Basket Material: Aluminium Die-Cast
Voice Coil Winding Material: Copper
Voice Coil Former Material: Fiberglass
Cone Material: Paper
Cone Treatment: Humidity Resistant Pulp
Surround Material: Treated Cloth
Dust Dome Material: Solid Paper
:
BEÉPÍTÉSI ADATOK:
Overall Diameter: 545 mm
Baffle Cutout Diameter: 497 mm
Mounting Holes: 8 holes 13x9 on Ø520 mm
Total Depth: 249 mm
:
THIELE/SMALL PARAMÉTEREK:
Re: 5.1 Ω
Qms: 9.95
Qts: 0.30
Cms: 65 µm/N
Vas: 255 l
X max: +/- 5.2 mm
N: 3.29 %
Fs: 34.6 Hz
Qes: 0.31
Mms: 325 g
Bxl: 36.10 Tm
Sd: 1661.9 cm²
X var: +/- 10.7 mm
Le (1KHz): 1.60 mH
